External Driver LED Tube Light

Applications
The LED tube light with external driver can be applied to indoor lighting, hotels, buildings, offices, plants, hospitals, schools, parking lots, supermarkets and meeting rooms.

Features
1. Compared to the traditional fluorescent light, this LED tube light adopts external driving power supply.
2. This LED tube light with external driver can be equipped with additional functions, such as high brightness and color rendering index.
3. For light source, this external driver LED tube light adopts Everlight's top-level LED, which features in high luminance and long use time.
4. In order to achieve the best heat emission effect, our LED tube light with external driver uses 0603 aluminum.
5. This LED tube with external power supply can save more than 60% energy than conventional traditional fluorescent tubes
6. The lifespan is more than 5000hrs.
7. The luminous efficiency can reach 100LM/W.
8. This LED tube light with external driver glows evenly, without light spot and dark zone.
9. Our LED tube with external power supply fully conforms to the ROHS standard

Operation and Notes
1. The LED tube with external power supply can directly replace the traditional fluorescent tube.
2. For inductive bracket, there is no need to reform the line. Only need to replace the starter on the fixture with a LED fuse.
3. For electronic support, it needs to remove the electronic ballast.
4. This LED tube light with external driver does not need special maintenance.

Parameters of External Driver LED Tube Light

Model No.	Dimension (mm)		Power (W)	LED  type	LED QTY (pcs)	Work voltage (V)	Lumen (lm)
FB-T860-10-ED	D28x600		10	SMD2835	48	AC85-265	850-1000
FB-T890-15-ED	D28x900		15	SMD2835	72	AC85-265	1250-1400
FB-T8120-20-ED	D28x1200		20	SMD2835	96	AC85-265	1700-1900
FB-T8150-25-ED	D28x1500		25	SMD2835	120	AC85-265	2000-2300
FB-T8180-32-ED	D28x1800		32	SMD2835	144	AC85-265	2350-2600
FB-T8240-38-ED	D28x2400		38	SMD2835	240	AC85-265	2980-3300
FB-T845-7-ED	D28x450		8	SMD2835	60	AC85-265	590-650
FB-T875-10-ED	D28x750		10	SMD2835	60	AC85-265V	850-1000
Color temperature: warm white 3000-3500K, natural white 4500-5700K, pure white 6000-6500K
Cover options		Milky cover, strips-cover, transparent cover

Packaging and Transportation
1.The LED tube light with external driver can be packed by square shape inner box or round shape inner box
2.Transport by express, by air or by sea, at clients' option

Model No.	Carton size L*W*H mm	QTY/Carton PCS	Net Weight KG	Gross weight KG
FBT860-10-ED	660x258x230	20	6.20	8.20
FBT890-15-ED	960x258x230	20	8.40	11.30
FBT8120-20-ED	1260x258x230	20	10.60	13.40
FBT8150-25-ED	1560x258x230	20	15.60	19.20

Founded in 2005, FusionBrite Technology Co., Ltd. is a professional manufacturer of LED tube light with external driver. Besides external driver LED tube light, we also offer PIR sensor LED tube, emergency LED tube, electronic ballast compliant LED tube, combined LED tube and dimmable LED tube light. Advanced light testing equipment is used to ensure the quality of our LED lights. Till now, our LED tube light with external driver has been exported to America, Britain, Korea, France, Germany, Spain, Turkey, Southeast Asia, Australia and Africa.
